Kompressor Maneurop Type Mtz56hl4bve (4.5Hp)
Hover to Zoom

Last Updated
09 Sep 2019
Minimum Order
1 unit

Specification of Kompressor Maneurop Type Mtz56hl4bve (4.5Hp)

 General Characteristics
 Model Number ( On Compressor Nameplate) Mtz56hl4bve
 Code Number For Singlepack* Mtz56-4Vi
 Code Number For Industrial Pack* * Mtz56-4Vm
 Drawing Number 8502012G
 Suction And Discharge Connections Rotolock
 Suction Connection 1-3/ 4 " Rotolock
 Discharge Connection 1-1/ 4 " Rotolock
 Suction Connection With Supplied Sleeve 7/ 8 " Odf
 Discharge Connection With Supplied Sleeve 3/ 4 " Odf
 Oil Sight Glass Threaded
 Oil Equalisation Connection 3/ 8' ' Flare Sae
 Oil Drain Connection None
 Lp Gauge Port Schrader
 Ipr Valve 30 Bar / 8 Bar
 Cylinders 2
 Swept Volume 96, 13 Cm3/ Rev
 Displacement @ Nominal Speed 16.7 M3/ H @ 2900 Rpm - 20.2 M3/ H @ 3500 Rpm
 Net Weight 39 Kg
 Oil Charge 1, 8 Litre, Poe - 160Pz
 Maximum System Test Pressure Low Side / High Side 25 Bar( G) / 30 Bar( G)
 Maximum Differential Test Pressure 30 Bar
 Maximum Number Of Starts Per Hour 12
 Refrigerant Charge Limit 5 Kg
 Approved Refrigerants R404a, R507a, R134a, R407c
 Electrical Characteristics
 Nominal Voltage 380-400V/ 3/ 50Hz - 460V/ 3/ 60Hz
 Voltage Range 340-440 V @ 50Hz - 414-506 V @ 60Hz
 Winding Resistance ( Between Phases) + / - 7% At 25º C 2.39 #
 Maximum Continuous Current ( Mcc) 12 A
 Locked Rotor Amps ( Lra) 64 A
 Motor Protection Internal Overload Protector
 Recommended Installation Torques
 Oil Sight Glass 50 Nm
 Power Connections / Earth Connection Nm / 2 Nm
 Mounting Bolts 15 Nm









Untuk keterangan lebih lanjut, silahkan download PDF ini :
